NKK TF4030 Cellulose Separator Roll (500m L × 60 mm W × 30 um T) for Battery or Supercapacitor - Lib-SP-NKK

NKK TF4030 Cellulose Separator Roll (500m L × 60 mm W × 30 um T) for Battery or Supercapacitor - Lib-SP-NKK

Lib-SP-NKK is a kind of cellulose separator roll with dimension of 500m L × 60 mm W × 30 um T, which can be used as separator membrane for battery and supercapacitor applications.

Specifications

  • Material:                     Cellulose
  • Thickness:                  27.6-32.4 um
  • Width :                         60 mm
  • Length:                       500 m
  • Density:                      0.35-0.45 g/cm3
  • Intensity:                    > 7.8 N/15mm
  • pH:                            5.5-8.0
  • Air Permeability:         80-150 s/100ml
  • Sold in roll only
$398.00
NKK TF4030 Cellulose Separator Roll (500m L × 60 mm W × 30 um T) for Battery or Supercapacitor - Lib-SP-NKK—
$398.00

Product Information

Shipping & Returns

Description

Lib-SP-NKK is a kind of cellulose separator roll with dimension of 500m L × 60 mm W × 30 um T, which can be used as separator membrane for battery and supercapacitor applications.

Specifications

  • Material:                     Cellulose
  • Thickness:                  27.6-32.4 um
  • Width :                         60 mm
  • Length:                       500 m
  • Density:                      0.35-0.45 g/cm3
  • Intensity:                    > 7.8 N/15mm
  • pH:                            5.5-8.0
  • Air Permeability:         80-150 s/100ml
  • Sold in roll only
