High Purity (99.999%) Copper (Cu) Particles (Φ3*3mm) as Evaporation Source for Conductive Metal Layer in Perovskite Solar Cells, 100 g/pack - PSC-CP

High Purity (99.999%) Copper (Cu) Particles (Φ3*3mm) as Evaporation Source for Conductive Metal Layer in Perovskite Solar Cells, 100 g/pack - PSC-CP

PSC-CP is high-purity Copper granules as the evaporation source for conductive metal layer used in Perovskite Solar Cells.

SPECIFICATION:

Chemical Formula
  • Cu
Purity
  • 99.999%
Quantity
  • 100 g/bottle
Appearance / Shape
  • Solid, Ø3 * 3 mm
Crystal Structure
  • Face-centered cubic (FCC)
Density
  • 8.96 g/cm3
Melting Point
  • 1084.62 °C
Boiling Point
  • 2562 °C
Heat of Fusion
  • 13.26 kJ/mol
Specific Heat Capacity
  • 24.86 J/(mol·K)
Coefficient of Thermal Expansion (25 °C)
  • 16.5 um/(m·K)
Thermal Conductivity
  • 401 W/(m·K)
Electrical Resistivity (20 °C)
  • 1.678 *10^-8 Ω­­·m
Young's Modulus
  • 110 - 128 MPa
Shear Modulus
  • 48 GPa
Bulk Modulus
  • 140 GPa
Poisson's Ratio
  • 0.34
Brinell Hardness
  • 238 - 878 MPa
Mohs Hardness
  • 3.0
SDS





$48.00
High Purity (99.999%) Copper (Cu) Particles (Φ3*3mm) as Evaporation Source for Conductive Metal Layer in Perovskite Solar Cells, 100 g/pack - PSC-CP
$48.00

Product Information

Shipping & Returns

Description

PSC-CP is high-purity Copper granules as the evaporation source for conductive metal layer used in Perovskite Solar Cells.

SPECIFICATION:

Chemical Formula
  • Cu
Purity
  • 99.999%
Quantity
  • 100 g/bottle
Appearance / Shape
  • Solid, Ø3 * 3 mm
Crystal Structure
  • Face-centered cubic (FCC)
Density
  • 8.96 g/cm3
Melting Point
  • 1084.62 °C
Boiling Point
  • 2562 °C
Heat of Fusion
  • 13.26 kJ/mol
Specific Heat Capacity
  • 24.86 J/(mol·K)
Coefficient of Thermal Expansion (25 °C)
  • 16.5 um/(m·K)
Thermal Conductivity
  • 401 W/(m·K)
Electrical Resistivity (20 °C)
  • 1.678 *10^-8 Ω­­·m
Young's Modulus
  • 110 - 128 MPa
Shear Modulus
  • 48 GPa
Bulk Modulus
  • 140 GPa
Poisson's Ratio
  • 0.34
Brinell Hardness
  • 238 - 878 MPa
Mohs Hardness
  • 3.0
SDS
